Overview
A process dial gauge offered in 2.5 inch and 4 inch sizes.
Series P400 gives you the larger 4 inch dial when the gauge is read from a distance, with the same glycerin fill and stainless steel case as the 2.5 inch model.
Specifications
Detailed specifications for the Series P400.
- Pressure range
- 0-100 psi, 0-300 psi, 0-600 psi
- Dial size
- 2.5 inch, 4 inch
- Connection type
- Bottom mount
- Fill type
- Glycerin filled
- Material
- Stainless steel
- Output type
- Analog (dial)
- Application
- General purpose, Process
- Accuracy
- +/-1.0% of full scale
- Connection size
- 1/4 inch NPT
- Pointer
- Black aluminum
- Operating temperature
- -4 to 158 F (-20 to 70 C)
- Window
- Glass
- Vibration resistance
- Filled for improved vibration damping
- Protection rating
- IP65
- Weight
- 0.4 lb (0.18 kg), 1.1 lb (0.5 kg)
Downloads
No downloads are listed for this instrument yet. Every specification is in the Specifications tab.
Compatibility
Process connection: 1/4 inch NPT, bottom mount.
Also in this catalogue with a 1/4 inch NPT connection: Pressure transmitter, Gauge snubber, Diaphragm seal.
Shipping and returns
This store runs in test mode: no payment is taken and no order is shipped.
Series P400 at a glance.
A process dial gauge offered in 2.5 inch and 4 inch sizes.
Key features
- Pressure range: 0-100 psi
- Dial size: 2.5 inch
- Connection type: Bottom mount
- Fill type: Glycerin filled
- Material: Stainless steel
